0.3Ton / 300kgs Freshwater Air Cooling Commercial Flake Ice Machine for Supermarket

0.3Ton / 300kgs Freshwater Air Cooling Commercial Flake Ice Machine for Supermarket

    • 0.3Ton / 300kgs Freshwater Air Cooling Commercial Flake Ice Machine for Supermarket
    • 0.3Ton / 300kgs Freshwater Air Cooling Commercial Flake Ice Machine for Supermarket
    • 0.3Ton / 300kgs Freshwater Air Cooling Commercial Flake Ice Machine for Supermarket
    • 0.3Ton / 300kgs Freshwater Air Cooling Commercial Flake Ice Machine for Supermarket
    • 0.3Ton / 300kgs Freshwater Air Cooling Commercial Flake Ice Machine for Supermarket
  • 0.3Ton / 300kgs Freshwater Air Cooling Commercial Flake Ice Machine for Supermarket

    Product Details:

    Place of Origin: China
    Brand Name: ECOICE
    Certification: CE
    Model Number: ECO0.3T-R4A
    Item: 0.3Ton / 300kgs Freshwater Air Cooling Commercial Flake Ice Machine for Supermarket
    Daily Ice Output: 0.3Ton / 24Hrs
    Cooling capacity: 2kw
    Compressor Input: 1.59kw
    Reductor Power: 0.25kw
    Water Inlet / Drain Pipe: 1/2"

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 unit
    Packaging Details: Packed by seaworthy wooden case
    Delivery Time: 20days - 35days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 10 unit per month
    Contact Now
    Detailed Product Description
    Item: 0.3Ton / 300kgs Freshwater Air Cooling Commercial Flake Ice Machine For Supermarket Ice Shape: Flake Ice
    Warranty: 2 Years Condition: New

    0.3Ton / 300kgs Freshwater Air Cooling Commercial Flake Ice Machine for Supermarket



    Technical Data As Below :
    1. Ambient Temp : 25 ºC ,Water Inlet Temp : 20ºC ;
    2. Evaporating Temp : -20 ºC ;
    3. Condensing Temp : 40 ºC ;
    4. Power supply: 3P/380V/50HZ
    5. Flake ice thickness:1.6-2.3 mm
    6. Refrigerant gas type : R404A



    Detailed Specification of Ice Flake Machine as below :


    Model ECO0.3T-R4A ECO0.5T-R4A ECO1T-R4A ECO1.2T-R4A ECO1.5T-R4A ECO2T-R4A ECO2.5T-R4A ECO3T-R4A
    Cooling Capacity 2KW 3.3KW 5.6KW 6.6KW 9.8KW 11.6KW 15.5 KW 17.2KW
    General Power 1.95KW 2.49KW 4.22KW 4.72KW 6.75KW 8.11KW 9.75KW 10.88KW
    Compressor Input 1.59KW 2.2KW 3.8KW 4.3KW 6.33KW 7.2KW 8.83KW 9.97KW
    Reductor Power 0.25KW 0.18KW 0.18KW 0.18KW 0.18KW 0.37KW 0.37KW 0.37KW
    Cooling Mode
    Air
    Cooling
    Air Cooling Air Cooling Air Cooling Air Cooling Air Cooling Air Cooling Air Cooling
    Weight 190KG 300KG 450KG 460KG 480KG 500KG 550KG 600KG
    DImension(mm) 1050*700*700 1280*800*800 1320*900*900 1320*900*900 1400*9500*1000 1500*1100*1200 1500*1100*1200 1700*1200*1320
    With ice bin 1050*800*1480 1280*1085*1850 1320*1185*2100 1320*1185*2100 1500*1420*2300 1735*1420*2500 1735*1520*2840 1875*1520*3050

    Model ECO5T-R4W ECO8T-R4W ECO10T-R4W ECO12T-R4W
    Daily Output (Ton/24Hrs) 5 8 10 12
    Cooling Capacity (KW) 38.7 54.1 76.5 83.3
    General Power (KW) 22.55 33 45.5 45.6
    Compressor Input (KW) 20.5 27.1 40.7 47.5
    Reductor Power(kw) 0.37 0.55 0.55 0.55
    Cooling Mode Water Cooling Water Cooling Water Cooling Water Cooling
    Cooling Tower(m3/h) 20 30 45 50
    Water Inlet/Drain Pipe 3/4",1/2" 3/4",1/2" 3/4",1/2" 3/4",1/2"
    Weight (kgs) 980 1670 2020 2260
    Dimension(mm) 1800*1500*1470 2200*1890*1650 2200*1900*1750 2200*1900*1900


    ** : We also could follow client detailed requirement to assemble correct machine .
