Name: Seafood Food Screw Compressor Water Chiller with Good Price Manufacture 1p for water cooling with low price
Brand: SHANDONG ECOICE REFRIGERATION CO.,LTD
SKU: ECOS-20122403
Price: 550.00 USD
Availability: InStock

Home Products Water Chiller

Seafood Food Screw Compressor Water Chiller with Good Price Manufacture 1p for water cooling with low price

Product Details:

Place of Origin:	China
Brand Name:	ECOICE
Certification:	CSA, ISO, CE
Model Number:	ECOS-20122403

Payment & Shipping Terms:

Minimum Order Quantity:	1pc
Price:	USD100-1000/PC
Packaging Details:	Standard Export Carton
Delivery Time:	7-30days
Payment Terms:	T/T, Western Union, L/C
Supply Ability:	500000PCS Per Year

Contact Now

Detailed Product Description

Application Fields:	Seafood Tank Or Aquarium Tanks	Voltage:	3N-380V/415V 50Hz/60Hz,AC220V--240V
Type:	Air-cooled/water Chiller/unit	Warranty:	12 Months
After-sales Service Provided:	Engineers Available To Service Machinery Overseas,Online Support	Certification:	CE,ISO9001
Refrigerant:	R22/R404a/R407c/R134a	Cooling Capability(kw):	220kW~3100kW
Evaporator:	Tube/shell/coil/plate/tank Heat Exchanger For Choice	Compressor Type:	Scroll Closed Type/reciprocating/rotary

Blast Water Cooled Industrial Chiller

Model		APTBL-1FCS	APTBL-2FCS	APTBL-3FCS
Capacity	w	2500	5000	7500
Compressor	kw	0.8	1.6	2.4
Chilled flow	L/min	7.2	14.4	21.6
Water ports	inch	1"	1"	1"
Pump motor	HP	0.5	0.5	0.5
Water tank	L	20	40	45
Weight	KG	73	106	165
Size	LWH(cm)	1053762.5	1053762.5	1053762.5
Power Supply	220V/50HZ			3N-380V /50HZ
Refrigerant	R22/R410a/R134a/R407C
Throttle device	Capillary Tube /Expansion valve
condenser	Fin tube type Air cooled condenser
Evaporator	Stainless steel water tank copper coil evaporator

A. The cooling capacity is based on the following standard temperature conditions

1 Chilled water return temperature 12 ° C

2 Chilled water outlet temperature 7 ° C

3 Condensation temperature 35 ° C

B Scope of working condition

1 Ambient temperature 30 ° C ° to 45 ° C

2 Chilled water outlet temperature difference 2.5 ° C to 7 ° C
3 Chilled water outlet temperature 5 ° C to 20 ° C

2 High quality core components of ECOICE chiller

All the plastic chiller spare parts are Top refrigeration brands including compressor, heat exchanger and air blower.
And the skilled workers from ECOICE can make sure each plastic chiller manufactured is under good cooling performance.

Seafood Food Screw Compressor Water Chiller with Good Price Manufacture 1p for water cooling with low price

Coaxial heat exchangers with excellent ability for heat exchanging and adaptation are widely used for:

1. Heat pump water heater condenser
2. Condenser/evaporator for water chiller
3. Condenser for pool heat pump
4. Condenser/evaporator for water(ground) source heat pump
5. Cooler or regenerator for CO2 heat pump air
6. Condenser/evaporator for marine AC
7. Condenser for ice machine
8. Evaporator for water purifier
9. Evaporation or condenser for mariculture constant temperature machine
10. Condenser for dish washer

Seafood Food Screw Compressor Water Chiller with Good Price Manufacture 1p for water cooling with low price
