Product Details:

Place of Origin: CHINA
Brand Name: ECOICE
Certification: CE
Model Number: ECO2520

Payment & Shipping Terms:

Minimum Order Quantity: 1 SET
Price: USD000-5000/SET
Packaging Details: WOODEN CASES
Delivery Time: 10-15 DAYS
Payment Terms: L/C, T/T, Western Union
Supply Ability: 500000 SET PER YEAR
Contact Now
Detailed Product Description
Material: Stainless Steel 304 Voltage: 380V
Freezing Type: Compressor System Refrigerant: R404A

Industrial Horizontal Fish Seafood IQF Plate Freezer with good quality and low price

Industrial Plate Freezer Refrigeration Contact Horizontal Plate Freezer

Industrial Plate Freezer Refrigeration Contact Horizontal Plate FreezerIndustrial Plate Freezer Refrigeration Contact Horizontal Plate FreezerIndustrial Plate Freezer Refrigeration Contact Horizontal Plate FreezerIndustrial Plate Freezer Refrigeration Contact Horizontal Plate FreezerIndustrial Plate Freezer Refrigeration Contact Horizontal Plate Freezer

Horizontal Plate Freezer makes the product into pieces, which is an economic and high efficient freezing method. It can adjust the distance of plates and compaction grade base on product. It suits for packed fish, shrimp, meat, and mixed food; vegetable, fruit, boxed cooked food; any bag or tray packed cake and molding products.

  • Short freezing time and high freezing quality, it is the best choice for massive food quick-freeze.
  • High heat exchange efficiency, quick freezing speed, the energy conservation effect is prominent.
  • Ensure food obtains the high quality as well as lower the cost to minimum.
  • The unit is high flexibility and vast range of application.
  •   Capacity(kg/shift) effective layers single board effective size(mm) cold consumption (kw) installed power(kw) outline dimension(L*W*Hmm) Weight(kg)
      fish cod shrimp
    ECO720 720 540 384 6 1700*1362 20 1.5 3250*1670*2500 3300
    ECO840 840 630 450 7 24 1.5 3250*1670*2600 3400
    ECO960 960 720 512 8 27 1.5 3250*1670*2700 3500
    ECO1200 1200 960 640 8 2150*1262 32 1.5 3600*1670*2700 4000
    ECO1350 1350 1080 720 9 35 1.5 3600*1670*2900 4150
    ECO1500 1500 1200 800 10 42 1.5 3600*1670*3000 4300
    ECO1650 1650 1320 880 11 46 1.5 3600*1670*3100 4450
    ECO1800 1800 1440 960 12 50 1.5 3600*1670*3200 4600
    ECO2100 2100 - 1200 10 2540*1569 58 1.5 3990*1980*3000 5000
    ECO2520 2520 - 1440 12 70 1.5 3990*1980*3200 5400




    Industrial Plate Freezer Refrigeration Contact Horizontal Plate FreezerIndustrial Plate Freezer Refrigeration Contact Horizontal Plate FreezerIndustrial Plate Freezer Refrigeration Contact Horizontal Plate FreezerIndustrial Plate Freezer Refrigeration Contact Horizontal Plate FreezerIndustrial Plate Freezer Refrigeration Contact Horizontal Plate FreezerIndustrial Plate Freezer Refrigeration Contact Horizontal Plate FreezerIndustrial Plate Freezer Refrigeration Contact Horizontal Plate Freezer

    Industrial Plate Freezer Refrigeration Contact Horizontal Plate FreezerIndustrial Plate Freezer Refrigeration Contact Horizontal Plate Freezer




If you want to get more detail information, please leave message and email address,
then we will contact you as soon as possible!
