Compressor Service Refrigeration Valve Chiller Spare Parts Rotary Type Locking Tecumseh Maneurop Tecumseh Valve

Product Details:

Place of Origin:	China
Brand Name:	ECOICE
Certification:	CE
Model Number:	MV-04

Payment & Shipping Terms:

Minimum Order Quantity:	5pcs
Price:	USD5-8
Packaging Details:	1pc/carton, then in standard export wooden case
Delivery Time:	5 days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	50000PCS/Month

Contact Now

Detailed Product Description

Material:	Brass And Stainless Steel	Connection Size:	1-3/8
Gas:	R134a	Item:	Compressor Service Refrigeration Valve Chiller Spare Parts Rotary Type Locking Tecumseh Maneurop Tecumseh Valve
Raw Material:	Carbon Steel	Temp. Of Operation:	-40 To +150 ºC

Product Description

Compressor Service Refrigeration Valve Chiller Spare Parts Rotary Type Locking Tecumseh Maneurop Tecumseh Valve

Rotalock valve can provide a convenient, removable access and isolation point for service.

Rotalock valves are widely used throughout the refrigeration and air conditioning industry

and are typically installed on compressors and pressure vessels.

Rotalock valve is applied in the compressor, liquid receiver or tube line connection of refrigeration system to control the open and close of refrigerant flow in system.

Its optimized body assures maximum flow while minimum pressure - drop.



Temp. of operation: -40 to +150 ºC.

Max. working pressure: 48 bar.

100% leakage tested.

ODF solder connections.

Tin coating or copper plating for optimized protection in all application condition.

Tin coated or brass nut for option.

Specification

Model No.	Valve Body mm*mm	L(mm)	Connection Size	Connection Size
			Copper Connection	Rotalock Valve Connection
			Inch	M Thread
MV-01	20*20	135	3/8	1"-14UNS
MV-02	35*35	195	1-1/8	1-3/4"-12UNS
MV-03	35*35	195	1-3/8	1-3/4"-12UNS
MV-04	30*30	160	3/4	1-1/4"-12UNF
MV-05	30*30	160	7/8	1-1/4"-12UNF
MV-06	20*20	135	1/2	1:-14UNS
MV-07	30*30	195	7/8	1-3/4"-12UNS
MV-08	20*20	135	5/8	1"-14UNS
MV09	20*20	135	5/8	1"-14UNS
